Ignition Coil Capacitor: Installation

Download the full database via torrent (~1.1 TB)
  1. Install the bolt to capacitor (Figure). Make sure that the ground strap is in place.
  2. Tighten bolt.
  3. Install the electrical connector to capacitor.
  4. Connect the negative battery cable.
