Fuel Tank Pressure Sensor (FTPS): Specifications: Specification

Download the full database via torrent (~1.1 TB)
Pressure [kPa (kgf/cm2 , in H2O) Output Voltage (V) [Vref = 5V]
-6.67 (-0.068, -26.8) 0.5
0 2.5
+6.67 (0.068, 26.8) 4.5
G12830262Courtesy of KIA MOTORS AMERICA, INC.
