Relay To Fuse Continuity Test
Remove fuel pump relay from circuit protection panel. Using an ohmmeter, check for continuity between fuse terminal and relay terminal 87 in panel. If there's continuity, go to POWER FEED TO RELAY POINTS TEST . If not okay, repair open in circuit. See Fig 1 .
