Control module, PSG 16 (595)

Download the full database via torrent (~1.1 TB)

Fig 1: PSG Control Module

G03719376

Courtesy of SAAB-SCANIA OF AMERICA, INC.

PSG CONTROL MODULE SPECIFICATION

No. of pins		56 on K switch and 56 on M switch
Power supply (+15 circuit)	pin no.	16(K)
P-bus (+)	pin no.	29(K)
P-bus (-)	pin no.	17(K)
